INF 40 Series - RS232 Commands

InFocus JTouch 4.0 RS232 Commands

INF6540e, INF7540e, INF8640e

Result

Set success
reply：34 30 31 2B 0D

Set fail
reply：34 30 31 2D 0D

RS232 Settings

Baud Rate: 9600bps
Data bit: 8bits
Parity: None
Stop bit: 1

Lan RS232 Settings

IP: Ip address
Port: 4664

Set List:

Number	Type	Part	Cmd(Hex)	Name	Command with ID（HEX，Default ID=1，have reply）	Note1	Note2
1	SET	Power	30	000 : backlight off	3A 30 31 53 30 30 30 30 0d
2							001 : backlight on	3A 30 31 53 30 30 30 31 0d
3							002 : power off	3A 30 31 53 30 30 30 32 0d
							003 : power on	3A 30 31 53 30 30 30 33 0d	Only support power on by port cable
3	SET	Treble	31	000 ~ 100	3A 30 31 53 31 30 35 30 0d	000-100	Test value:50
4	SET	Bass	32	000 ~ 100	3A 30 31 53 32 31 30 30 0d	000-100	Test value:100
5	SET	Balance	33	000 ~ 100	3A 30 31 53 33 30 35 30 0d	000-100	Test value:50
6	SET	Contrast（TV对比度）	34	000 ~ 100	3A 30 31 53 34 30 35 30 0d	000-100	Test value:50
7	SET	Brightness（TV亮度）	35	000 ~ 100	3A 30 31 53 35 30 35 30 0d	000-100	Test value:50
8	SET	Sharpness（TV锐度）	36	000 ~ 100	3A 30 31 53 36 30 31 30 0d	000-100	Test value:10
9	SET	Sound Mode	37	000 : Movie	3A 30 31 53 37 30 30 30 0d
10							001 : Standard	3A 30 31 53 37 30 30 31 0d
11							002 : Custom	3A 30 31 53 37 30 30 32 0d
12							003 : Classroom	3A 30 31 53 37 30 30 33 0d
13							004 : Meeting	3A 30 31 53 37 30 30 34 0d
14	SET	Volume	38	000 ~ 100	3A 30 31 53 38 30 35 30 0d	000-100	Test value:50
15	SET	Mute	39	000: Off	3A 30 31 53 39 30 30 30 0d
16	SET	Mute	39				001: On	3A 30 31 53 39 30 30 31 0d
19	SET	Video Source	3A	000 : VGA	3A 30 31 53 3A 30 30 30 0d
20							001 : HDMI1	3A 30 31 53 3A 30 30 31 0d
21							002: HDMI2	3A 30 31 53 3A 30 30 32 0d
22							003 : AV	3A 30 31 53 3A 30 30 33 0d
23							022 : HDMI4	3A 30 31 53 3A 30 32 32 0d
24							021 : HDMI3	3A 30 31 53 3A 30 32 31 0d
25							031 : VGA2	3A 30 31 53 3A 30 33 31 0d
26							032 : VGA3	3A 30 31 53 3A 30 33 32 0d
27							051 : TV	3A 30 31 53 3A 30 35 31 0d
28							101 : android	3A 30 31 53 3A 31 30 31 0d
29							103 : Slot in PC	3A 30 31 53 3A 31 30 33 0d
30							007 : Display Port	3A 30 31 53 3A 30 30 37 0D
31							102 : android +	3A 30 31 53 3A 31 30 32 0D
32	SET	Aspect Ratio	3B	000 : 16:9	3A 30 31 53 3B 30 30 30 0d
33							001 : 4:3	3A 30 31 53 3B 30 30 31 0d
34							002 : PTP	3A 30 31 53 3B 30 30 32 0d
35	SET	Language	3C	000: English	3A 30 31 53 3C 30 30 30 0d	Set Android channel language
36							001: Français	3A 30 31 53 3C 30 30 31 0d
37							002: Español	3A 30 31 53 3C 30 30 32 0d
38							003: 繁中	3A 30 31 53 3C 30 30 33 0d	Set the language to Chinese繁体
39							004: 简中	3A 30 31 53 3C 30 30 34 0d	Set the language to Chinese简体
40							005: Português	3A 30 31 53 3C 30 30 35 0d
41							006: German	3A 30 31 53 3C 30 30 36 0d
42							007: Dutch	3A 30 31 53 3C 30 30 37 0d
43							008: Polish	3A 30 31 53 3C 30 30 38 0d
44							009: Russia	3A 30 31 53 3C 30 30 39 0d
45							010:Czech	3A 30 31 53 3C 30 31 30 0d
46							011:Danish	3A 30 31 53 3C 30 31 31 0d
47							012:Swedish	3A 30 31 53 3C 30 31 32 0d
48							013:Italian	3A 30 31 53 3C 30 31 33 0d
49							014:Romanian	3A 30 31 53 3C 30 31 34 0d
50							015:Norwegian	3A 30 31 53 3C 30 31 35 0d
51							016:Finnish	3A 30 31 53 3C 30 31 36 0d
52							017:Greek	3A 30 31 53 3C 30 31 37 0d
53							018:Turkish	3A 30 31 53 3C 30 31 38 0d
54							019:Arabic	3A 30 31 53 3C 30 31 39 0d
							020:Japanse	3A 30 31 53 3C 30 32 30 0d
55							021:Ukraine	3A 30 31 53 3C 30 32 31 0d
69	SET	Picture Mode	3D	000 : standard	3A 30 31 53 3D 30 30 30 0d
70							001 : bright	3A 30 31 53 3D 30 30 31 0d
71							002 : soft	3A 30 31 53 3D 30 30 32 0d
72							003 : customer	3A 30 31 53 3D 30 30 33 0d
53	SET	Hue (Color)	3E	000 ~ 100	3A 30 31 53 3E 30 33 30 0d	000-100	Test value:30
74	SET	Backlight	3F	000 ~ 100	3A 30 31 53 3F 30 35 30 0d	000-100	Test value:50
75	SET	Color Temp	40	000 : Cool	3A 30 31 53 40 30 30 30 0d
76							001 : Standard	3A 30 31 53 40 30 30 31 0d
77							002 : Warm	3A 30 31 53 40 30 30 32 0d
57	SET	Reomte comtrol command	41	000 : Vol +	3A 30 31 53 41 30 30 30 0d
58							001 : Vol -	3A 30 31 53 41 30 30 31 0d
59							010 : Remote 上	3A 30 31 53 41 30 31 30 0d
60							011 : Remote 下	3A 30 31 53 41 30 31 31 0d
61							012 : Remote 左	3A 30 31 53 41 30 31 32 0d
62							013 : Remote 右	3A 30 31 53 41 30 31 33 0d
63							014 : Remote OK	3A 30 31 53 41 30 31 34 0d
64							020 : Remote Menu Key	3A 30 31 53 41 30 32 30 0d
65							021 : Remote Input source	3A 30 31 53 41 30 32 31 0d
66							022 : Remote Exit	3A 30 31 53 41 30 32 32 0d
67							031 : Blank	3A 30 31 53 41 30 33 31 0d	The screen lights up
68							032 : Freeze	3A 30 31 53 41 30 33 32 0d
69	SET	Reomte comtrol(IR LOCK)	42	000: Disable	3A 30 31 53 42 30 30 30 0d	Unlock Remote
70	SET	Reomte comtrol(IR LOCK)	42				001: Enable	3A 30 31 53 42 30 30 31 0d	Lock Remote

Get List:

Number	Type	Part	Cmd(Hex)	Name	Command with ID（HEX，Default ID=1，have reply）	Reply	Note
1	GET	Power	30	000 :backlight off	3A 30 31 47 30 30 30 30 0D	3A 30 31 72 30 30 30 30 0D
2								001 : backlight on	3A 30 31 72 30 30 30 31 0D
								002: power off	3A 30 31 72 30 30 30 32 0D	Only support get state by Port cable
3	GET	Treble	31	000~100	3A 30 31 47 31 30 30 30 0D	3A 30 31 72 31 30 35 30 0D	Example: reply 050
4	GET	Bass	32	000~100	3A 30 31 47 32 30 30 30 0D	3A 30 31 72 32 30 35 30 0D	Example: reply050
5	GET	Balance	33	000~100	3A 30 31 47 33 30 30 30 0D	3A 30 31 72 33 30 35 30 0D	Example: reply050
6	GET	Contrast	34	000~100	3A 30 31 47 34 30 30 30 0D	3A 30 31 72 34 30 35 30 0D	Example: reply050
7	GET	Brightness	35	000~100	3A 30 31 47 35 30 30 30 0D	3A 30 31 72 35 30 35 30 0D	Example: reply050
8	GET	Sharpness	36	000~100	3A 30 31 47 36 30 30 30 0D	3A 30 31 72 36 30 31 30 0D	Example: reply010
9	GET	Sound Mode	37	000 : Movie	3A 30 31 47 37 30 30 30 0D	3A 30 31 72 37 30 30 30 0D
10								001 : Standard	3A 30 31 72 37 30 30 31 0D
11								002 : Custom	3A 30 31 72 37 30 30 32 0D
12								003 : Classroom	3A 30 31 72 37 30 30 33 0D
13								004 : Meeting	3A 30 31 72 37 30 30 34 0D
14	GET	Volume	38	000~100	3A 30 31 47 38 30 30 30 0D	3A 30 31 72 38 30 35 30 0D	Example: reply050
15	GET	Mute	39	000: Off	3A 30 31 47 39 30 30 30 0D	3A 30 31 72 39 30 30 30 0D
16	GET	Mute	39		3A 30 31 47 39 30 30 30 0D			001: On	3A 30 31 72 39 30 30 31 0D
17	GET	Video Source	3A	000 : VGA	3A 30 31 47 3A 30 30 30 0D	3A 30 31 72 3A 30 30 30 0D
18								001 : HDMI1	3A 30 31 72 3A 30 30 31 0D
19								002: HDMI2	3A 30 31 72 3A 30 30 32 0D
20								003 : CVBS / AV	3A 30 31 72 3A 30 30 33 0D
21								022 : HDMI4	3A 30 31 72 3A 30 32 32 0D
22								021 : HDMI3	3A 30 31 72 3A 30 32 31 0D
23								031 : VGA2	3A 30 31 72 3A 30 33 31 0D
24								032 : VGA3	3A 30 31 72 3A 30 33 32 0D
25								051 : TV	3A 30 31 72 3A 30 35 31 0D
26								101 : android	3A 30 31 72 3A 31 30 31 0D
27								103 : Slot in PC	3A 30 31 72 3A 31 30 33 0D
28								007 : Display Port	3A 30 31 72 3A 30 30 37 0D
29								102 : android +	3A 30 31 72 3A 31 30 32 0D
30	GET	Aspect Ratio	3B	000 : 16:9	3A 30 31 47 3B 30 30 30 0D	3A 30 31 72 3B 30 30 30 0D
31								001 : 4:3	3A 30 31 72 3B 30 30 31 0D
32								002 : PTP	3A 30 31 72 3B 30 30 32 0D
33	GET	Language	3C	000: English	3A 30 31 47 3C 30 30 30 0D	3A 30 31 72 3C 30 30 30 0D	Get the Language of Android channel
34								001: Français	3A 30 31 72 3C 30 30 31 0D
35								002: Español	3A 30 31 72 3C 30 30 32 0D
36								003: 繁中	3A 30 31 72 3C 30 30 33 0D
37								004: 简中	3A 30 31 72 3C 30 30 34 0D
38								005: Português	3A 30 31 72 3C 30 30 35 0D
39								006: German	3A 30 31 72 3C 30 30 36 0D
40								007: Dutch	3A 30 31 72 3C 30 30 37 0D
41								008: Polish	3A 30 31 72 3C 30 30 38 0D
42								009: Russia	3A 30 31 72 3C 30 30 39 0D
43								010:Czech	3A 30 31 72 3C 30 31 30 0D
44								011:Danish	3A 30 31 72 3C 30 31 31 0D
45								012:Swedish	3A 30 31 72 3C 30 31 32 0D
46								013:Italian	3A 30 31 72 3C 30 31 33 0D
47								014:Romanian	3A 30 31 72 3C 30 31 34 0D
48								015:Norwegian	3A 30 31 72 3C 30 31 35 0D
49								016:Finnish	3A 30 31 72 3C 30 31 36 0D
50								017:Greek	3A 30 31 72 3C 30 31 37 0D
51								018:Turkish	3A 30 31 72 3C 30 31 38 0D
52								019:Arabic	3A 30 31 72 3C 30 31 39 0D
								020:Japanse	3A 30 31 72 3C 30 32 30 0D
53								021:Ukraine	3A 30 31 72 3C 30 32 31 0D
54	GET	Picture Mode	3D	000 : standard	3A 30 31 47 3D 30 30 30 0D	3A 30 31 72 3D 30 30 30 0D
55								001 : bright	3A 30 31 72 3D 30 30 31 0D
56								002 : soft	3A 30 31 72 3D 30 30 32 0D
57								003 : customer	3A 30 31 72 3D 30 30 33 0D
58	GET	Hue (Color)	3E	000~100	3A 30 31 47 3E 30 30 30 0D	3A 30 31 72 3E 30 33 30 0D	Example: reply030
59	GET	Backlight	3F	000~100	3A 30 31 47 3F 30 30 30 0D	3A 30 31 72 3F 30 35 30 0D	Example: reply050
60	GET	Color Temp	40	000 : Cool	3A 30 31 47 40 30 30 30 0D	3A 30 31 72 40 30 30 30 0D
61								001 : Standard	3A 30 31 72 40 30 30 31 0D
62								002 : Warm	3A 30 31 72 40 30 30 32 0D
63	GET	Reomte comtrol(IR LOCK)	42	000: Disable	3A 30 31 47 42 30 30 30 0D	3A 30 31 72 42 30 30 30 0D
64	GET	Reomte comtrol(IR LOCK)	42		3A 30 31 47 42 30 30 30 0D			001: Enable	3A 30 31 72 42 30 30 31 0D
